Warning! The Grenton CLU does not validate scripts. Lua is not a strongly typed language, and many issues in scripts only surface at runtime. The CLU may enter emergency mode if an error in the script is encountered during execution. In such cases, you should fix the script or restore a previously working configuration. I recommend making a backup of your project before uploading complex scripts and making or applying changes to scripts incrementally.

Old fashioned and rusty shutters

Shutters

In Lua, objects are de facto tables. A table is a map of key-value pairs, and the map’s keys can be treated like object fields. You can refer to these fields using the . operator. With the use of Metatables and Metamethods, you can create classes and instances of those classes. This technique is used in the Shutter:new function. The special variable self is equivalent to this in other programming languages. Lua is a dynamic language and in many ways resembles JavaScript.

Controlling Roller Shutters Link to heading

The example below demonstrates how to use object-oriented features of Lua to control shutters and groups of shutters. The variable Shutter acts as an interface for the objects representing individual shutters. The default implementation of the up and down methods iterates over nested objects. The implementation provided at the end of this post allows you to create hierarchies/nesting of shutter objects. A leaf object in the hierarchy has conrete implementations of up and down methods that control a specific module. Consider the following hierarchy as an example:

|-GroundFloor
  |-Garage
  |-Kitchen
    |-Left
    |-Right
  |-LivingRoom
    |-North
    |-East
|-Upstairs
  |-Bedroom
    |-Bigger
    |-Smaller
  |-Office

Shutters can be controlled individually or with groups using the appropriate nesting level. Example calls for the configuration above:

-- lower all shutters in the house:
zWave->Shutters:down()

-- lower shutters on the ground floor:
zWave->Shutters.GroundFloor:down()

-- lower shutters in the bedroom:
zWave->Shutters.Upstairs.Bedroom:down()

-- raise a specific shutter:
zWave->Shutters.GroundFloor.Kitchen.Left:up()

Complete code implementing a different example hierarchy:

local Shutter = {
  up = function(self)
    self.op(self, function(o) o:up() end)
  end,

  down = function(self)
    self.op(self, function(o) o:down() end)
  end,

  op = function(self, fclosure)
    for k, shutter in pairs(self) do
      if type(shutter) == "table" then
        fclosure(shutter)
      end
    end
  end
}

function Shutter:new (o)
  o = o or {}
  setmetatable(o, self)
  self.__index = self
  return o
end

local shutters = Shutter:new{
  Office = Shutter:new{
    up = function()
      zWave->x100000001_ROLLER_SHUTTER_01->MoveUp(0)
    end,
    down = function()
      zWave->x100000001_ROLLER_SHUTTER_01->MoveDown(0)
    end,
  },
  LivingRoom = Shutter:new{
    East = Shutter:new{
      up = function()
        zWave->x100000001_ROLLER_SHUTTER_02->MoveUp(0)
      end,
      down = function()
        zWave->x100000001_ROLLER_SHUTTER_02->MoveDown(0)
      end,
    },
    South = Shutter:new{
	  Left = Shutter:new{
	    up = function()
	      zWave->x100000002_ROLLER_SHUTTER_01->MoveUp(0)
	    end,
	    down = function()
	      zWave->x100000002_ROLLER_SHUTTER_01->MoveDown(0)
	    end,
	  },
	  Right = Shutter:new{
	    up = function()
	      zWave->x100000002_ROLLER_SHUTTER_02->MoveUp(0)
	    end,
	    down = function()
	      zWave->x100000002_ROLLER_SHUTTER_02->MoveDown(0)
	    end,
	  }
	},
    West = Shutter:new{
      Left = Shutter:new{
        up = function()
          zWave->x100000003_ROLLER_SHUTTER_01->MoveUp(0)
        end,
        down = function()
          zWave->x100000003_ROLLER_SHUTTER_01->MoveDown(0)
        end,
      },
      Right = Shutter:new{
        up = function()
          zWave->x100000003_ROLLER_SHUTTER_02->MoveUp(0)
        end,
        down = function()
          zWave->x100000003_ROLLER_SHUTTER_02->MoveDown(0)
        end,
      }
    }
  }
}

zWave->Shutters = shutters

Installation Link to heading

  1. Create a user-defined variable in user features of type OTHER with an initial value of 0
  2. Create a new script as described above
  3. Set the script to run on the CLU’s OnInit event
  4. Set the function call, e.g. zWave->Shutters:down(), as the action for a panel button or wall switch key

Final Notes Link to heading

To better understand object-oriented features of Lua and the related syntax, I recommend reviewing the bank account example in the Programming in Lua manual.

An alternative to the presented implementation could be grouping shutters using bit fields stored in a single Number variable, using bitwise operations like AND, OR, etc. This code would likely be less readable but simpler from the perspective of the Lua interpreter in the CLU.

You can also try calling methods directly on hidden module objects. For example:

ROL1234:execute(0, 0)

The first parameter of the execute method is the operation code (MoveUp, MoveDown, etc.). The second parameter is the actual argument for the operation (e.g., time). There is no documentation explaining what each code means — you have to discover them through reverse-engineering.
Module objects can be encapsulated/decorated in your own objects or put in an array and iterated over. The problem is that after a CLU rediscovery, object identifiers may change.

About Grenton Link to heading

Grenton is a smart home system developed in Poland. It is highly customizable thanks to Lua scripts that can be provided by the user them self. It comprises set of modules and external panels that can be connected together with the communication bus. System configuration is build on and deployed with proprietary IDE based on Eclipse. CLU is a central unit keeping track of the current state of the system and controlling other modules. To some extend modules can work independently from CLU in a distributed logic mode without connection to the central unit.
